RGB ON SCREEN DISPLAY
1. Press TV/RGB button on the remote control to switch between TV and RGB modes. 2. Press MENU on the remote control to display the different features in RGB MODE. 3. Press the THUMB STICK , , , buttons to highlight a different feature.
TV /RGB
ME
NU
EXIT
4. Press EXIT on the remote control to quickly exit from a menu.
SELECT
USING THE RGB INPUT
Video Aspect Setup Power Swivel Move
SEL
Sel
This part of the screen shows which Remote Control buttons to use.
STANDBY (RED) ON (GREEN)
MAIN POWER
32�/42� Only
Video Aspect Setup Move
SEL
Sel
This part of the screen shows which Remote Control buttons to use.
STANDBY (RED) ON (GREEN)
50� Only
NOTES: 1. 2. The Power Swivel OSD will not be available for the 50� model. When the Power Swivel connection cable is disconnected, the Power Swivel OSD will disappear.
70
|
|
|
> |
|
