CASIO AQ163W-2B
Owner's Manual

Operation Guide 3358/3368/3798
Setting the Analog Time
Perform the procedure below when the time indicated by the analog hands does not match the time of the digital display.

To adjust the analog time
1. In the Timekeeping Mode, press C five times to enter the Hand Setting Mode. 2. Hold down A until the current digital time starts to flash, which indicates the analog setting screen. 3. Press D to advance the analog time setting by 20 seconds. � Holding down D advances the analog time setting at high speed. � If you need to advance the analog time setting a long way, hold down D until the time starts advancing at high speed, and then press B. This locks the highspeed hand movement, so you can release the two buttons. High-speed hand movement continues until you press any button. It will also stop automatically after the time advances 12 hours or if an alarm (daily alarm, Hourly Time Signal, or countdown beeper) starts to sound. 4. Press A to exit the setting screen. � The watch will automatically adjust the minute hand slightly to match its internal second count when you exit the setting screen. � To return to the Timekeeping Mode, press C.

Progress Beeper When the progress beeper is turned on, the watch uses beeps to signal countdown progress as described below. � Starting from five minutes before the end of the countdown, the watch emits four short beeps at the top of each countdown minute. � 30 seconds before the end of the countdown, the watch emits four short beeps. � The watch emits a short beep for each of the last 10 seconds of the countdown. � If the countdown start time is six minutes or greater, the watch emits a short beep for each second of the final 10 seconds before the five-minute point is reached. Four short beeps are emitted to signal when the five-minute point is reached.

To configure the countdown timer 1. While the countdown start time is on the display in the Countdown Timer Mode, hold down A until the current countdown start time starts to flash, which indicates the setting screen. � If the countdown start time is not displayed, use the procedure under �To use the countdown timer� to display it. 2. Press C to move the flashing in the sequence shown below to select other settings.
Start Time Auto-repeat

Progress Beeper

World Time
City code

3. When the setting you want to change is flashing, use B and D to change it as described below. World Time digitally displays the current time in 27 cities (29 time zones) around the world. � All of the operations in this section are performed in the World Time Mode, which you enter by pressing C.
Setting Start Time Auto-repeat Progress Beeper Screen Button Operation Use D (+) and B (�) to change the setting. � You can set a start time in the range of 1 to 60 minutes in 1-minute increments. Press D to toggle auto-repeat on ( displayed) and off ( displayed). Press D to toggle the progress beeper on (ON) and off (OF).

Current time for the selected city code

To view the time in another city In the World Time Mode, press D to scroll eastwardly through city codes. � For full information about city codes, see the �City Code Table�. � If the current time shown for a city is wrong, it probably means there is a problem with your Timekeeping Mode time and/or Home City code settings. Go to the Timekeeping Mode and make the necessary adjustments.

4. Press A to exit the setting screen. � You can also perform steps 1 and 2 of the above procedure whenever you need to view the current auto-repeat and progress beeper settings.

To toggle a city code time between Standard Time and Daylight Saving Time 1. In the World Time Mode, use D to display the city code whose Standard Time/ Daylight Saving Time setting you want to change. 2. Hold down A for about two seconds to toggle between Daylight Saving Time (DST
indicator displayed) and Standard Time (DST indicator not displayed). � The DST indicator is on the display whenever you display a city code for which Daylight Saving Time is turned on. � Note that the DST/Standard Time setting affects only the currently displayed city code. Other city codes are not affected. � Note that you cannot switch between Standard Time and Daylight Saving Time while GMT is selected as the city code.
DST indicator

To use the countdown timer Press D while in the Countdown Timer Mode to start the countdown timer. � The countdown timer operation continues even if you exit the Countdown Timer Mode. � Press D while a countdown operation is in progress to
pause it. Press D again to resume the countdown. � To completely stop a countdown operation, first pause it (by pressing D), and then press A. This returns the countdown time to its starting value.

Stopwatch
The stopwatch lets you measure elapsed time, split times, and two finishes. � The display range of the stopwatch is 59 minutes, 59.99 seconds. � The stopwatch continues to run, restarting from zero after it reaches its limit, until you stop it. � The stopwatch measurement operation continues even if you exit the Stopwatch Mode. � Exiting the Stopwatch Mode while a split time is frozen on the display clears the split time and returns to elapsed time measurement. � All of the operations in this section are performed in the Stopwatch Mode, which you enter by pressing C.
Minutes 1/100 second Seconds Split indicator

Module 3358

Module 3368

Module 3798

Countdown Timer
Seconds

The countdown timer can be set within a range of one minute to 60 minutes. An alarm sounds when the countdown reaches zero. The countdown timer also has an auto-repeat feature and a progress beeper that signals the progress of the countdown. � All of the operations in this section are performed in the Countdown Timer Mode, which you enter by pressing C.

Split indicator

Module 3358

Module 3368

Module 3798

To measure times with the stopwatch
Elapsed Time Start Split Time Start Two Finishes Start Split
(Split indicator displayed)

Configuring the Countdown Timer
Minutes

The following are the settings you should configure before actually using the countdown timer. Countdown start time; Auto-repeat on/off; Progress beeper on/off � See �To configure the countdown timer� for information about setting up the timer.

Stop

Re-start

Stop

Clear

Split release

Stop

Clear

Auto-repeat When auto-repeat is turned on, the countdown automatically restarts from the countdown start time when it reaches zero. If left running, the countdown is repeated a total of eight times, after which it stops automatically. When auto-repeat is turned off, the countdown stops when it reaches zero and the display shows the original countdown start time. � Pressing D while an auto-repeat countdown is in progress pauses the current countdown. You can resume the auto-repeat countdown by pressing D, or you can press A to reset to the countdown time starting value. Countdown Timer Beeper Operations The watch beeps at various times during a countdown so you can keep informed about the countdown status without looking at the display. The following describes the types of beeper operations the watch performs during a countdown. Countdown End Beeper The countdown end beeper lets you know when the countdown reaches zero. � When the progress beeper is turned off, the countdown end beeper sounds for about 10 seconds, or until you press any button to stop it. � When the progress beeper is turned on, the countdown end beeper sounds for about one second.

Split
First runner finishes. Display time of first runner.

Stop
Second runner finishes.

Split release
Display time of second runner.

Clear

2
