MECHANICAL PARTS LIST 1 / 1
REF. NO. PART NO. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 8A-AR3-006-010 8A-AR5-003-010 8A-AR5-007-010 8A-AR5-005-010 8A-AR5-006-010 8A-AR3-045-010 8A-AR3-007-010 8A-AR3-047-010 8A-AR3-009-010 87-CE3-023-010 8Z-AR1-020-110 8A-AR5-001-010 8A-AR3-024-010 8A-AR3-020-010 88-912-161-110 8A-AR3-021-010 8A-AR5-602-010 88-AR1-209-010 88-904-101-110 8A-AR3-643-010 88-908-101-110 8A-AR5-004-010 8Z-NB8-240-010 8Z-AR1-021-110 88-AR1-218-010 KANRI DESCRIPTION NO. KNOB,RTRY JOG PANEL,FR U KEY,ASSY,ENTER KEY,ASSY,DOLBY WINDOW,DISP U KNOB,RTRY VOL RING,VOL RING,FUN REFLECTOR,FUN BADGE,AIWA 30N SILV RING,FOOT SIL CABI,FR U KEY,BAL KEY,ECO FF-CABLE,12P 1.25 160MM KEY,POWER FL,9-BT-172GNK R GUIDE,FL FF-CABLE, 4P 1.25 100MM FF-CABLE,32P 1.25 430MM FF-CABLE, 8P 1.25 10MM CABI,STEEL COVER, PL FOOT,REAR HLDR,PWB H8.9 REF. NO. PART NO.
! !
26 27 28 29 30 31 32 33 A B C D E F G H I J K L
8Z-AR4-601-010 87-085-189-010 87-A80-110-010 8A-AR5-206-010 8A-AR3-011-010 88-AR1-203-010 8A-AR5-002-010 87-033-209-010 87-067-703-010 87-591-095-410 87-067-633-010 87-067-581-010 87-067-632-010 87-067-585-010 87-067-579-010 87-067-641-010 87-067-584-010 87-067-689-010 87-078-191-010 87-721-095-410
KANRI DESCRIPTION NO. PT,ZAR-4(U) BUSHING, CORD (U) AC CORD ASSY,U SPT-2W HLDR,HT-SINK L BTN,SP HLDR,TU PANEL,REAR UBM TERMINAL, EARTH TAPPING SCREW, BVT2+3-10 TAPPING SCREW, QIT+3-8 (GLD) TAPPING TAPPING TAPPING TAPPING TAPPING SCREW, SCREW, SCREW, SCREW, SCREW, BVT2+3-8 BVT2+3-15 BVT2+3-15 BVTT+4-6 BVT2+3-8
UTT2+3-8(W/O SLOT)BL TAPPING SCREW, BVT2+3-6 TAPPING SCREW, BVTT+3-8 S-SCREW,IT+4-10 QT2+3-8GLD W/O SLOT
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color B Black C Cream D Orange G Green H Gray L Blue LT Transparent Blue N Gold P Pink R Red S Silver ST Titan Silver T Brown V Violet W White WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange GM Metallic Green YM Metallic Yellow DM Metallic Orange
