BJC-1000
Part 3: Operating Instructions
Paper thickness lever Adjusts the gap between the print head and the paper. Set this lever according to the type of print media that you are using.
Figure 3-11 Name of the Parts and Their Functions (2)
Paper thickness lever Adjusts the gap between the print head and paper according to the thickness of the paper. There are two settings: left for plain paper, high resolution paper, transparencies, back print film, glossy paper and high glossy film; and right for thick paper, envelopes, and banner paper.
Left Right
Figure 3-12 Paper Thickness Lever
