Customizing the Main Unit � INSTALLATION Mode
Adjusting the source input offset � SOURCE INPUT OFFSET
You can keep the volume balance among source components by taking an average of the output level from each source component.
Locking the settings � SETUP LOCK
You can lock in the settings under which have been entered into the Main Unit.
1 2
Turn off the power. Press and hold SOURCE SELECT + and BACK simultaneously, and then turn on the power. �SETUP LOCK� appears for a few seconds, then the display window displays the SETUP LOCK window. Press the R cursor or r cursor to turn SETUP LOCK on or off. The display window changes as follows: SETUP LOCK r LOCK [OFF] LOCK [ON]
Rr Rr
1 2
Turn off the power. Press and hold ZONE + and ALL ZONE MUTING simultaneously, and then turn on the power. �SOURCE OFFSET� appears in the display window for a few seconds. Press the R cursor or r cursor repeatedly to select a source number. Each time you press the R cursor or r cursor, the display window changes cyclically as shown below. SOURCE OFFSET (Appears for a few seconds)
r
�
Setting up the Main Unit
3
3
(Appears for a few seconds)
t SOURCE 1
Y
Rr Rr Rr
4
Press ENTER when you have finished. The display window returns to the NORMAL mode.
Notes
� The following are the preferences that can be locked in in the SETUP LOCK mode. All settings in the LEARN mode. All settings in the SETUP mode. Settings for the Disc Search. The adjustment of SOURCE OFFSET. All Clear. � When you select settings that cannot be changed, �LOCKED!� appears for a few seconds, then the display window returns to the NORMAL mode.
SOURCE 2 t SOURCE 8
4 5
Press ENTER. The display window displays the OFFSET settings. Press the R cursor or r cursor to adjust the offset. Each time you press the R cursor or r cursor, the display window changes cyclically as shown below.
t OFFSET 0dB OFFSET -1dB OFFSET -2dB OFFSET -3dB OFFSET -4dB t OFFSET -5dB
Rr Rr Rr Rr Rr Rr
6
Press ENTER when you want to adjust the offset for other source components. The step goes back to step 3. Press CANCEL when you have finished. The display window returns to the NORMAL mode.
Note
In a zone where SOURCE INPUT OFFSET is ON, the actual volume level is lower than the displayed volume level.
7
24US
|
|
|
> |
|
|
