4. Selected of music cannot be searched.
4
Press the play key. (PAUSE)
VREF-TSO
Vref Vref
Is waveform at R572 (TSO) like that shown in Fig. 29 ? No
Yes
* Readjust VR501.
Figure 29
VREF-TSO A VREF B A=B A+B=0.6V<
Is waveform at R572 (TSO) like that shown in Fig. 30 ? No
Yes
* Check wire connector CN502. * Check pickup.
Figure 30
Press the� � or � � key.
VREF-FMFB
Is waveform at pin 36 (FMFB) of IC502 like that shown in Fig. 31.
Yes
* Check around IC503. * Check sled motor.
Figure 31
No
VREF-TKIC
Is waveform at pin 33 (TKIC) of IC502 like that shown in Fig. 32 ?
Yes
* Check around IC501.
Figure 32
No * Check around pins 36 and 33 of IC502.
19
|
|
|
> |
|
