the big video recorder format s-vhs many features delicate in loading system of the cassette. Such machines are no longer manufactured, it would be too expensive.
 ;
THIS MANUAL IS VERY GOOD AND VERY CLEAR
PLEASE NOTE IT DOES NOT CONTAIN THE SETUP INFORMATION TO ALIGHN THE GEARS IN THE CD MECH IT DOES SHOW ALL THE PARTS AND THEIR LOCATIONS .
;
Complete service and operation manual. All schematics are there, all circuit boards AND add-on boards. Including exploded views ,component names and specifications. Also electrical and mechanical adjustment procedures are in this manual. This manual also covers the more advanced BR-S811E unit. Scan quality is fair and usable.
;
High quality scan of original Service Manual. Everything´s fine!
;
Good scan of the original service manual. All schematics and adjustment procedures are there. It helped me to fix a long lasting problem with the tracking circuitry. The manual also includes the supplementals 1,2 and 3. Included are; electrical schematic's , pcb layout's, mechanical drawing's and exploded views, disassembly manual and maintenance procedures. 236 pages.
TEST MODE
1. How to activate CD test mode 1) Remove D937 (1SS133) from the main circuit board, and connect the terminal No.45 of a microcomputer and GND line with a wire. (Fig. 1) 2) Connect +12V to ACC/BACK UP and � (minus) to the ground of CONNECTOR ASSY. 3) Turn on the power. Test mode will be activated and turn on all LCD lights (5 seconds later, only the display will change to Demo Mode.) (Fig. 2)
Fig. 1
Fig. 2
2. How to cancel CD test mode 1) Turn off the power supply to ACC/BACK UP. 2) Remove the connection wire between the terminal No.45 of the main circuit board and the GND line, and solder back D937 (1SS133). 3) Disconnect +12V from ACC/BACK UP and � (minus) from the ground of CONNECTOR ASSY.
� 29 �
