CFM-S1
2-6. NOTE ON INSTALATION
Dress the lead wires as shown in figure.
Main board (KH102)
To jack board
Main board (KH101)
To battery terminal board
Main board (KH1)
Fine tune board (KH2)
To speaker (SP1) Power board (KH901)
MIC (ECM101)
Power board (CN901)
2-7. DIAL POINTER SETTING
4Screw + BVTP 3X14 Chassis(A) 3 2Fit the pointer to the chassis(B). Pointer 1 Turn the knob(tune) fully counterclockwise.
Chassis(B) 5 Set the left side of the pointer to the convex Pointer portion (a) on the Chassis(B) chassis(B). (a)
6
Chassis(B)
6 Hold the left side of pointer, then insert the gear section of pointer to groove of chassis(A). 6
7Bracket(P) Pointer
5
|
|
|
> |
|
