PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC SYMBOL ! IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY AND PERFORMANCE CAN BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY ! , USE ONLY THE REPLACEMENT PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION :
N.S.P :
Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram. Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors. Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type. Not available as service parts.
PACKING & ACCESSORIES
REF.NO. PART NO. 614 325 8056 614 319 7430 614 319 7447 614 325 8094 614 325 8421 645 047 0516 645 005 1227 645 046 8322 614 318 9404 645 057 4696 614 325 7875 DESCRIPTION CARTON CASE CUSHION,REAR CUSHION,FRONT INSTRUCTION MANUAL INSTRUCTION SHEET POLY SHEET-0900X0300*NC ASSY,ANTENA,LOOP ASSY,ANTENA,LOOP LID,BATTERY,SERVICE REMOCON,RB-DA2000 ASSY,BOX,SPEAKER,SPEAKER(L,R)
FIXING PARTS
REF.NO. Y01 Y02 Y03 Y04 Y05 Y06 Y07 Y08 PART NO. DESCRIPTION 411 156 2105 SCR S-TPG BIN 2.3X6, PANEL+PANEL FRONT 411 021 3503 SCR S-TPG BIN 3X10, F-PANEL+LATCH,CAM 411 021 3503 SCR S-TPG BIN 3X10, F-PANEL+DECK MECHA 614 129 9136 LUG,LEAD FIX 411 020 8905 SCR S-TPG BRZ+FLG 3X10, F-PANEL+ASSY.GEAR,DECK 411 021 3503 SCR S-TPG BIN 3X10, SWITCH,PWB+MTG CD 411 021 1806 SCR S-TPG BIN 2.6X10, MTG CD+DA11 411 092 0906 WASHER Z 2.6X10X0.5, MTG CD+DA11 411 020 8905 SCR S-TPG BRZ+FLG 3X10, F-PANEL+ASSY.GEAR,CD 411 021 4906 SCR S-TPG BIN 3X20, F-PANEL+MOUNTING,CD 411 021 3503 SCR S-TPG BIN 3X10, MAIN PCB+MTG CD 411 184 0906 SCR S-TPG BIN 2.3X10, LID CD+DEC WINDOW CD 412 032 6408 SPECIAL SCREW,REAR+P-TRANS 411 021 3503 SCR S-TPG BIN 3X10, REAR+STOPPER 411 098 7800 SCR S-TPG FLT 3X12, REAR+MTG(L/R) 411 021 4906 SCR S-TPG BIN 3X20, REAR+PANEL,FRONT 411 021 3503 SCR S-TPG BIN 3X10, REAR+ANT TERMINAL, REAR+AUDIO TERMINAL 411 021 3503 SCR S-TPG BIN 3X10, REAR+MTG CD
or
CABINET & CHASSIS
REF.NO. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 PART NO. 614 325 7981 614 326 3043 614 320 3520 614 319 7096 614 323 2230 614 325 7967 614 319 7072 614 326 3050 614 309 7969 614 303 1277 614 323 2162 614 319 6945 614 325 7974 614 325 8025 614 310 3899 614 307 2072 614 319 7119 614 322 2125 614 303 0263 614 319 7201 614 307 8821 614 303 0256 614 319 7102 614 325 8230 614 316 1172 614 325 7929 614 325 6014 DESCRIPTION COVER,DECK DEC,WINDOW,DECK SPRING,WIRE,DOOR DECK LID,CASSETTE PANEL ASSY,PANEL,FRONT KNOB,VOLUME DEC,WINDOW,LCD ASSY,GEAR,LID,CASSETTE LATCH,CAM,DECK,DOOR,LOCKING BUTTON,OPERATION,11 KEYS BUTTON,RIGHT,4 KEYS BUTTON,POWER REFLECTOR,STANDBY,LED SPACER,MECHA,MTG CD+DA11 COVER,PICK-UP MOUNTING,CD ASSY,GEAR,LID CD LATCH,PUSH,CD DOOR LOCKING SPRING,WIRE,DOOR CD PULLEY LATCH,MAGNET LID,CD DEC,WINDOW,CD STOPPER ASSY,CABINET,REAR ASSY,MECHA,DA11T3CN-SASH Y09 Y10 Y11 Y12 Y13 Y14 Y15 Y16 Y17
Y18
ELECTRICAL PARTS
REF.NO. 51 52 or 53 or 54 55 56 57 58 PART NO. DESCRIPTION 614 322 2279 ASSY,WIRE,AMP-TAPE MECHA 614 326 3760 FLEXIBLE FLAT CABLE, FRONT-AMP 614 327 0874 FLEXIBLE FLAT CABLE, FRONT-AMP 614 326 2794 FLEXIBLE FLAT CABLE, CD-CD MECHA 614 327 0836 FLEXIBLE FLAT CABLE, CD-CD MECHA 614 316 8041 ASSY,WIRE,CD-CD MECHA 614 274 2013 CORD,ID CONNECTOR,FM ANT 423 016 7908 FUSE 250V 2.5A 645 050 7373 TRANS,POWER 645 016 9939 CORD,POWER-1.74MK
-4-
|
|
|
> |
|
