Section
03
Operating this unit
EQ FLAT SUPER BASS (S-BASS) Flat Super bass
Adjusting 7-band graphic equalizer
For CUSTOM 1 and CUSTOM 2 equalizer curves, you can adjust the level of each band. ! A separate CUSTOM 1 curve can be created for each source. If you make adjustments when a curve other than CUSTOM 2 is selected, the equalizer curve settings will be memorized in CUSTOM 1. ! A CUSTOM 2 curve can be created common to all sources. If you make adjustments when the CUSTOM 2 curve is selected, the CUSTOM 2 curve will be updated. 1 Recall the equalizer curve you want to adjust. See Recalling equalizer curves on the previous page. 2 Press AUDIO to select 7-band graphic equalizer adjustment. Frequency and the level (e.g., 50HZ 0) appears in the display. 3 Press c or d to select the equalizer band to adjust. Each press of c or d selects equalizer bands in the following order: 50HZ�125HZ�315HZ�800HZ�2KHZ� 5KHZ�12.5KHZ 4 Press a or b to adjust the level of the equalizer band. Each press of a or b increases or decreases the level of the equalization band. +6 to �6 is displayed as the level is increased or decreased.
# You can then select another band and adjust the level.
! CUSTOM 1 and CUSTOM 2 are adjusted equalizer curves that you create. Adjustments can be made with a 7-band graphic equalizer. ! When EQ FLAT is selected, no supplement or correction is made to the sound. This is useful to check the effect of the equalizer curves by switching alternatively between EQ FLAT and a set equalizer curve. % Press EQ to select the equalizer. Press EQ repeatedly to switch between the following equalizers: POWERFUL (PWRFL)�NATURAL�VOCAL� CUSTOM 1�CUSTOM 2�EQ FLAT� SUPER BASS (S-BASS)
Adjusting equalizer curves
The factory supplied equalizer curves, with the exception of EQ FLAT, can be adjusted to a fine degree (nuance control). 1 Press AUDIO to select PWRFL. PWRFL appears in the display. If the equalizer curve has been previously selected, the curve of that previously selected will be displayed instead of PWRFL. 2 Press c or d to select an equalizer curve. 3 Press a or b to adjust the equalizer curve. Each press of a or b increases or decreases the equalizer curve respectively. +6 to �4 (or �6) is displayed as the equalizer curve is increased or decreased.
# The actual range of the adjustments are different depending on which equalizer curve is selected. # The equalizer curve with all frequencies set to 0 cannot be adjusted.
5 Press BAND to cancel the 7-band graphic equalizer adjustment.
Adjusting loudness
Loudness compensates for deficiencies in the low- and high-sound ranges at low volume.
38
En
|
|
|
> |
|
