2.2 Disc centering mechanism
A
1. In the case of a 12 cm disc, the centering arm R L will open by the disc being transported and both the lock arm R L being pushed. Furthermore, the disc will be centered by the stopper of either the clamp arm or the centering arm R and stopped, and the clamping motion will be taken.
12 cm DISC positioning section
B
Lock arm
Lock arm Centering arm
Centering arm
Clamp arm
C
2. In the case of an 8 cm disc, if a disc is inserted being shifted to the left or the right, the disc will first hit the lock arm R or L. As the lock arm R and L are coupled via the centering arm R and L and the lock will not be released unless both are pushed, the disc will be restricted by the fixed lock arm and centered. The disc pushes out the detection arm while being centered, the disc stops at a position where the motion of the detection arm is completed, and the clamping motion will be taken.
D
E
8 cm DISC positioning section
F
CX-3212
5 6 7 8
21
|
|
|
> |
|
|
