Note
If each of the front or rear speakers are not placed at an equal distance from your listening position, set the distance according to the closest speaker.
OFF ON
The test tone is not emitted from the speakers. The test tone is emitted from each speaker in sequence while adjusting balance or level.
� LEVEL (FRONT)
Varies the level of the front speakers. Be sure to set �TEST TONE� to �ON� for easy adjustment. The default adjustments are in parentheses.
L (0 dB) R (0 dB) CENTER (0 dB) Set this between �6 dB and 0 dB in 0.5 dB increments. Set this between �6 dB and 0 dB in 0.5 dB increments. Set this between �12 dB and 0 dB in 0.5 dB increments.
Adjusting the speaker volume and level
1 2 3
Select �SPEAKER SETUP� in the Setup Display. Select �TEST TONE� and set to �ON.�
You will hear the test tone from each speaker in sequence.
From your listening position, select �LEVEL (FRONT)� or �LEVEL (REAR)� and adjust the value using X/x.
The test tone is emitted from both left and right speakers simultaneously.
SUBWOOFER For DVDs: (DVD: �5 dB/ (When �SIZE� are set to the SUPER default settings): AUDIO CD: Set this between �10 dB 0 dB) and +10 dB in 0.5 dB increments. (When �SIZE� are not set to the default settings): Set this between �15 dB and +5 dB in 0.5 dB increments. For Super Audio CDs: Set this between �10 dB and +10 dB in 0.5 dB increments.
4
Select �TEST TONE� and set to �OFF� to turn off the test tone.
Note
The test tone signals are not output from the digital jack.
� LEVEL (REAR)
Varies the level of the rear speakers. Be sure to set �TEST TONE� to �ON� for easy adjustment. The default adjustments are in parentheses.
L (0 dB) R (0 dB) Set this between �12 dB and 0 dB in 0.5 dB increments. Set this between �12 dB and 0 dB in 0.5 dB increments.
To adjust the volume of all the speakers at one time
Use the amplifier�s (receiver�s) volume control.
� TEST TONE
The speakers will emit a test tone. Use this when you use the 5.1CH OUTPUT jacks and adjust �LEVEL (FRONT)� and �LEVEL (REAR).�
