TV Virtual Surround Settings (TVS)
When you connect a stereo TV or 2 front speakers, TVS (TV Virtual Surround) lets you enjoy surround sound effects by using sound imaging to create virtual rear speakers from the sound of the front speakers (L: left, R: right) without using actual rear speakers. TVS was developed by Sony to produce surround sound for home use using just a stereo TV. If the player is set up to output the signal from the DIGITAL OUT (COAXIAL or OPTICAL) jack, the surround effect will only heard when �DOLBY DIGITAL� is set to �D-PCM� (page 68).
2 Press SUR repeatedly to select
one of the TVS sounds.
Refer to the following explanations given for each item. � TVS DYNAMIC � TVS WIDE � TVS NIGHT � TVS STANDARD
To cancel the setting
Select �OFF� in step 2. �TVS DYNAMIC Creates virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers (shown below). This mode is effective when the distance between the front L and R speakers is short, such as with built-in speakers on a stereo TV.
TV
Sound Adjustments
1 Press SUR during playback.
The following display appears.
TVS DYNAMIC
�TVS WIDE Creates virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers. The virtual speakers are reproduced as shown in the illustration below. This mode is effective when the distance between the front L and R speakers is short, such as with built-in speakers on a stereo TV.
TV
�TVS NIGHT Large sounds, such as explosions, are suppressed, but the quieter sounds are unaffected. This feature is useful when you want to hear the dialog and enjoy the surround sound effects of �TVS WIDE� at low volume.
c continued
51
|
|
|
> |
|
