5. NOTE ON MOUNTEING SLED MOTOR
1) Push the sled motor ass�y 1 toward direction A. (See Fig. 4) 2) Tighten two screws 2 (M1.7 � 2.5).
1 Sled motor ass�y
A 2 Two screws (M1.7 � 2.5)
Fig. 4
3) Raising the MD block ass�y 3 90 º with the side down. confirm that the optical pick-up 4 falls by self weight. (See Fig. 5) 4) Further, with the front side of MD block ass�y 3 up, confirm that the optical pick-up falls by self weight.
3 MD block ass�y
Upper
Upper
Front side
Lower
Front side 4 Optical pick-up
Lower
Fig. 5
�6�
|
|
|
> |
|
|
