PIONEER DVR-530H-S (UK)
Owner's Manual

Recording

06

� Depending on your camcorder, you can use this recorder�s remote to control the camcorder using the ,,, , , and buttons. 7 Use the / press ENTER. buttons to select �Start Rec� and

Playing your recordings on other DVD players
VR mode Video mode

Stop 1.02.22 Control with these buttons Start Rec Pause Rec Stop Rec HDD Rem. SP

Stop

(2h00m/DVD) 32h45m

Most regular DVD players can play finalized discs recorded in Video mode. A number of players (including many Pioneer models) can also play DVD-RW discs recorded in VR mode, finalized or not. Most players will not play VR mode DVD-R discs, although some DVDROM drives and DVD recorders may be able to (finalization might be necessary). Check the manual that came with the player to check what kinds of discs it will play. When you finalize a Video mode disc, a title menu is created from which you can select titles when you play the disc. There are a number of different styles of title menu to choose from to suit the content of the disc. All the title menus are navigated in the usual way, pressing MENU or TOP MENU to display the menu, then using the / / / followed by ENTER to select titles and start playback.

� Recording is automatically paused if the recorder detects no signal, or a copy-protected signal. Recording restarts when there is a non-copyprotected signal. � You can pause or stop the recording by selecting Pause Rec or Stop Rec from the on-screen display. You cannot control the camcorder from this remote control during recording. � If you restart recording after stopping the camcorder, the first few seconds of the camcorder tape will not be recorded. Use the pause button on your camcorder instead and recording will start immediately. � HDD and DVD-RW (VR Mode) only: A chapter marker is inserted every time there is a break in the timecode on the DV tape. This happens when the recording is stopped or paused then restarted, for example. � While recording, you cannot exit the DV recording screen using the HOME MENU or RETURN button. � See also DV-related messages on page 115 if you encounter an error while using the DV IN jack. Frequently Asked Questions � I can�t get my DV camcorder to work with the recorder! Check that the DV cable is properly connected. Also make sure that what you�re trying to record is not copy-protected. If it still doesn�t work, try switching off the camcorder then switch back on. � There�s a picture, but no sound! Try switching the DV Input setting (see DV Input on page 103) between Stereo 1 and Stereo 2.1

Finalizing a disc
VR mode Video mode

Finalizing �fixes� the recordings in place so that the disc can be played on a regular DVD player or computer equipped with a suitable DVD-ROM drive.2 Note that the disc name will appear in the title menu after you finalize a disc. Make sure the disc name is as you want it before you finalize the disc as it can�t be changed afterwards. If you want to rename the disc, see Input Disc Name on page 95 before starting the steps below.

Important � Once you�ve finalized a disc recorded in Video mode, you can�t edit or record anything else on that disc. However, the finalization on a DVD-RW disc maybe �undone�; see Undo Finalize on page 96 for how to do this. � A VR mode disc can still be recorded and edited on this recorder even after finalizing. 1 Load the disc you want to finalize. Make sure that the recorder is stopped before proceeding.

Note 1.If the audio subcode on the DV tape cannot be read correctly, the audio type will not switch automatically. You can switch the audio manually from the External Audio setting (page 102). 2.If the TV line system of the disc is different to the current setting of the recorder, you will not be able to finalize the disc. See Additional information about the TV system settings on page 107 for how to change the recorder�s setting.

59
En
