Text excerpt from page 2 (click to view)
1698/1918-2
ALARM MODE
Hourly time signal on indicator Mode indicator
A
When the Daily Alarm is turned on, the alarm sounds for 20 seconds at the preset time each day. Press any button to stop the alarm after it starts to sound. When the Hourly Time Signal is turned on, the watch beeps B every hour on the hour.
To set the alarm time
1. Hold down A while in the Alarm Mode until the hour digits start to flash on the display. The hour digits flash because they are selected. C � This operation automatically turns on the Daily Alarm. L 2. Press M to change the selection in the following Hour : Minutes sequence.
Hour Minutes
M
Alarm on indicator
3. Press C to increase the selected digits. Holding down C increases the selection at high speed. � The format (12-hour and 24-hour) of the alarm time matches the format you select for normal timekeeping. � When setting the alarm time using the 12-hour format, take care to set the time correctly as a.m. (no indicator) or p.m. (P indicator). 4. After you set the alarm time, press A to return to the Alarm Mode.
To turn the Daily Alarm and Hourly Time Signal on and off
Press B while in the Alarm Mode to change the status of the Daily Alarm and Hourly Time Signal in the following sequence. [Alarm On Indicator/Hourly Time Signal On Indicator]
Both ON
Both OFF
Daily Alarm Only
Hourly Time Signal Only
To test the alarm
Hold down C while in the Alarm Mode to sound the alarm.
