PJ-LC9(C12H)
6. Position the air �lter and �lter cover into place. �PUSH� mark (1) Set an air �lter into place. Push the points of �PUSH� mark. (Usual �lter cover) (2) Interlocking the tabs, snap the cover into place. Tabs Tabs
(Filter cover for bottom-up use)
7. Please reposition and reconnect the projector, to return as before. Then turn the projector on. 8. Reset the �lter time using the FILTER TIME function in the OPTION menu. (1) Press the MENU button to display a menu. When the EASY MENU has appeared, please skip the next step (2). (2) Point at the �OPTION� in the left column of the menu using �/� button, then press the � button. (3) Point at the �FILTER TIME� using �/� button, then press the � button. A dialog will appear. (4) Press the � button to select �RESET� on the dialog. It performs resetting the �lter time. NOTE � Please replace the air �lter when it is damaged or too soiled, and also when you replace the lamp. � Please reset the �lter time only when you have cleaned or replaced the air �lter, for a suitable indication about the air �lter. � The projector may display the message such as �CHECK THE AIR FLOW� or turn off the projector, to prevent the internal heat level rising.
22
|
|
|
> |
|
