Let's recording
31
HM-381MD (En)
Pause the recording
In regard to track numbers at the time of recording
When a part without sound continues for 2 sec. or more during recording, the track number is automatically increased by �1� when the next sound enters. When classic music continues with low sound, the track number may be increased by �1�. (The track number is not increased during recording of the tape or tuner input.) The erroneously set track number can be erased later. When it is desired to increase the track No. during recording, press the TRACK EDIT key during recording to record a track No. at that position. The track numbers are used at the time of playback to find the start of tracks, for programming, etc. Press during recording.
TRACK EDIT
6
MD
Lights
RANDOM PGM REPEAT ALL SLEEP A.P.S. O.T.T. PROG. 1 2
STEREO
R·D·S EON EON TP TA PTY
TRACK NO. FM AM PM
TOTAL AUTO TUNED
0018P000 001WR54:32�
kHz MHz BEST HITS O.T.E.
NR T.E.
MD EDIT
TITLE SEARCH
The recordable time for the MD is displayed. ÷ Press the key again to resume recording. At this time, the track number is incremented by �1�. ÷ Recording can also be started by pressing the �MD rec� key.
÷ With digital recording from a CD, the track number is increased when the track changes. At the time of recording from a CD, the track number may be incremented when CD playback starts. This occurs because of a signal included in the digital signal from the CD. Delete unwanted track numbers under reference to �TRACK ERASE or ALL ERASE�. O
Stop the recording
STOP
Note
7
Basic section
3. Start recording.
MD rec
3
1 Press the �MD rec� key (the unit enters record-pause mode). 2 When the preparation is complete, press the �MD rec� key again. 3 Play the music source to be recorded.
÷ For recording from a CD, read �One-touch recording�.
t
4. Remove the minidisc after the end of recording.
0
Always remove the minidisc after recording.
�WRITING� displayed during the minidisc ejection operation indicates that the data associated with recording or editing is being written on the disc. Do not apply vibration or shock to the unit while this message is displayed.
4
In regard to display messages
Recording is not possible when one of the following messages is displayed. �DISC FULL� : The minidisc is full. �PROTECTED� : The write protect tab is open. �PLAY ONLY� : The minidisc is only for playback. \ Erase unrequired tracks. \ Close it. \ Insert a recordable disc.
