ADJUSTMENT
MECHANICAL EXPLODED VIEW 1 / 1
A MAIN C.B
VOLUME
VR 1
PHONES SFR 51 J1
PH
1
12
2
1. Tape Speed Adjustment Settings : � Test tape : TTA�100 (Tape center) � Test point : PHONES JACK (J1) � Adjustment location : SFR51 Method : Play back the test tape and adjust SFR51 so that the frequency is 3000Hz±10Hz.
2. Head Azimuth Adjustment Settings : � Test tape : � Test point : � Ajustment location: Method:
TTA�300 PHONES JACK (J1)
Head azimuth adjustment screw Play back the test tape and adjust the screw
so that the output becomes maximum and same phase.
