ADJUSTMENT
PRACTICAL SERVICE FIGURE
u
MAIN C.B
Tape speed: Wow & flutter: Take-up torque: F.F torque: Rew torque: Back tension: S/N ratio: Distortion : Noise level :
ImEEEl
Frequency response: Test tape:
3000Hz * 60Hz Less than 0.5% (RMS) 35- 50g-cm (FWD) More than 36g-cm 60- 170g-cm 1.5- 4.5g-cm (FWD) More than 43dB (PB, DC) Less than 3.0% (PB, DC) Less than 7.OmV (Vol MAX, PB, DC) Less than 0.5mV (Vol MIN, PB, DC) 63Hz +3dB/-6dB - 8kHz * 3dB TTA-1OO TTA-21O TTA-320
60 12
1, Tape Speed Adjustment Settings : Test tape :
q q q
Method :
TT�A-1OO (TAPE CENTER) Test point: PHONES JACK (Jl) Adjustment location : SFR1 Play back the test tape and adjust for 3015Hz t 10Hz,
2. Head Azimuth Adjustment Settings : Test tape : TTA-320 Test point: PHONES JACK (Jl) Adjustment location : Head azimuth adjustment screw Method: Play back the test tape and adjust the screw so that the output becomes maximum and same phase.
q q q
