FRONT C.B.
1. To reassemble the Lid, window, slide all knobs on the Lid, window and all switches on the FRONT C.B to the MAX position.
A A
2. Slide the Lid, window in the direction of the arrows A into the Lid cassette, followed by the rest of the hooks. Ensure all catches are hooked and movement of switches are smooth.
Hocks Front C.B. Hocks All knobs at max position Hocks
3 switches at max position
Cassette lid
Lid windon
4
|
|
|
> |
|
