SECTION 3 DISASSEMBLY
� This set can be disassembled in the order shown below.
Set
Lid, Battery Case
Case (Front) Section Case (Rear) Section Main Board
Note: Follow the disassembly procedure in the numerical order given.
LID, BATTERY CASE
2 boss 3 lid, battery case
2 boss
1
CASE (FRONT) SECTION, CASE (REAR) SECTION
1 screw
2 claw 5 case (rear) section speaker (SP101)
#
3
3 Remove the two solders speaker lead (SP101).
2 three claws
2 three claws 4 case (front) section
�4�
