7. GENERAL INFORMATION
7.1 DIAGNOSIS 7.1.1 DISASSEMBLY
A
- Removing the Case (not shown) 1. Remove the Case.
- Removing the Cassette Mechanism Module (Fig.1)
Cassette Mechanism Module
1
B
Remove the four screws and then remove the Cassette Mechanism Module.
-
Removing the Grille Assy (Fig.1)
1
1
2
Remove the two screws and then remove the Grille Assy.
1
C
1 2
2
Grille Assy
- Removing the Tuner Amp Unit (Fig.2)
Fig.1
1
D
Remove the screw.
2
2 2
2 3 4
E
Remove the three screws.
Straight the tabs at three locations indicated. Remove the screw and then remove the Tuner Amp Unit.
4 1
3
F
3
3
Tuner Amp Unit
36 1 2
KEH-P7035/XN/ES
Fig.2
