KLV-S40A10
2-2-5. SIDE BRACKET ASSY AND S1 TOP SHIELD REMOVAL
3 Six screws (+BVST 3X6) 1 Two screws (+BVST 3X6) 4 S1 top shield (UL) 2 Side bracket assy (U)
Harness with connector (LVDS)
2-2-6. H2 BOARD REMOVAL
3 Two screws (+BVTP 3X10) 4 H2 board 1 Two screws (+BVST 3X6) 2 Holder side jack assy
KLV-S26/S32/S40A10 (UC/WB/CND/MX)
2-9
|
|
|
> |
|
|
