Preparing for surround sound
0 Use the MULTI CONTROL knob or keys to select the appropriate Surround speaker setting. If you have selected �LRG� as the Center speaker setting, 1 SURR NML (normal) : Average size Surround speakers are connected to this model. 2 SURR LRG (large) : Large Surround speakers are connected to this model. 3 SURR OFF : Surround speaker setting mode to this model is OFF. If you have selected other than �LRG� as the Center speaker setting, 1 SURR ON : Surround speaker setting mode to this model is ON. 2 SURR OFF : Surround speaker setting mode to this model is OFF. ! Press the SETUP key again to accept the setting. � The Subwoofer re-mix setting indication �SW RE-MIX� scrolls across the display.
3 Press the SETUP key. � The test tone is turned off. This model enters the mode for inputting the distance to the speakers. 4 For MANUAL selection, press the SETUP key each time to select the speaker channel.
5Input the distance to the speakers.
1 Select the DISTANCE from the set up displays and press the SETUP key again. 2 Measure the distance from the listening position to each of the speakers. Jot down the distance to each of the speakers. Distance to Front speakers : ____ feet (meters) Distance to Center speaker : ____ feet (meters) Distance to Surround speakers : ____ feet (meters) 3 Use the MULTI CONTROL knob or keys to select the distance to the Front speakers. The speaker indicator to be adjusted blinks.
� If Subwoofer is turned OFF, Subwoofer re-mix setting is not visible. @ Use the MULTI CONTROL knob or keys to select the appropriate Subwoofer re-mix setting. 1 RMX ON : Subwoofer re-mix set mode to this model is ON. 2 RMX OFF : Subwoofer re-mix set mode to this model is OFF. # Press the SETUP key to accept the setting.
Indication in feet Indication in meters � The allowable setting range is 1 to 30 feet (0.3m to 9.0m) , adjustable in 1 foot (0.3m) increments. 4 Press the SETUP key to accept the settings. 5 Repeat steps 3 and 4 to input the distance for each of the speakers. 6 Setup is complete when the EXIT indication appears.
4Adjust the speaker volume level.
From your usual listening position, adjust the volume levels. The volume levels from each speaker should be the same. � In step 4 and 5, indications appear only for the selected channels of the speakers that require adjusting.
1 Press the SETUP key to begin TEST TONE. � This model enters the speaker volume level adjustment mode. The selection of AUTO/MANUAL TEST TONE is done by the MULTI CONTROL knob or keys. 1 AUTO 2 MANUAL 2 Press the SETUP key again to select either AUTO or MANUAL. Use the MULTI CONTROL knob or keys to adjust the volume level of the test tone output from the speaker channel to be adjusted. For AUTO selection, the test tone is heard from the speakers in the following sequence for 2 seconds each:
� The speakers you have selected should appear on the display. Confirm that all the speakers have been correctly selected. 7 Press the SETUP key to exit the SETUP mode.
Input level adjustment (analog sources only)
If the input level of an analog source signal is too high, the CLIP indicator will blink to indicate the source signal. Adjust the input level.
1 Use the INPUT SELECTOR knob to select the source of which the input level you want to adjust. � You can store a separate input level for each input source. 2 Press the SOUND key repeatedly until the �INPUT� indication appears. 3 Use the MULTI CONTROL knob or keys to adjust the input level.
� If you change the volume level settings for the speakers while listening to music, the settings referred to on this page are also changed. § � If any of the speaker is set as OFF during SP SETUP, the TEST TONE adjustment for the speaker will be skipped.
� The input level may be adjusted to any one of three settings: 0dB, -3dB, and -6dB. (The initial setting is 0dB.) 4 Press the SOUND key again to return to the input indication.
17 EN
|
|
|
> |
|
