9
8
BTP4 x 12
B4 x 16
6
BTP4 x 12
3
BTP4 x 12
1 7 2
4
BTP4 x 12
2 5
B4 x 16
3 6
B4 x 16 B4 x 16
No. 1 2 3 4 5 6 7 8 9
Part No. 3-202-265-01 3-202-266-01 3-202-267-01 3-202-268-01 3-202-269-01 3-202-270-01 3-202-745-01 3-603-694-01 3-605-962-02 3-603-695-01 3-605-961-02
SP Description o o o o o o o o o o o COVER (SMALL), CASTER CASTER (38), UNIVERSAL CASTER (90) HANDLE, PULL STAND COVER (LARGE), CASTER COVER (SMALL 2), CASTER INTERNAL CUSHION 1 (LC-DN7) INTERNAL CUSHION (BOTTOM) (LC-DN5) INTERNAL CUSHION 2 (LC-DN7) INTERNAL CUSHION (UPPER) (LC-DN5) Note Parts marked with �o� at SP (Supply Code) column of the spare parts list may not be stocked. Therefore, the delivery date will be delayed.
Printed in Japan
LC-DN5/DN7 (WW) J, E 3-202-565-01
Sony Corporation
Broadcasting & Professional Systems Company
1999. 3 08 ©1999
|
|
|
> |
|
