It's complete and helpful manual with good quality of scan. Thanks very much.
;
The service was quick and simple, finding the service manual easy and it appears to be the original with colour schematics. It contained the info I was after and so sorted the problem.
I have copied it to CD and attached the envelope to the inside back cover of the owners manual. Good manual and excelent service. Robin Wood, Wood Electronics, New Zealand.
;
Exactly what was needed to assess the product - excellent value and great service
 ;
Nice to have the service manual for the Sony DCR-TRV345E now. The document is of excellent quality.
;
MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
Power supply circuit
1) Power supply circuit for CPU, GATE ARRAY and RAMs.
When the main batteries are set, the voltage (9V) is applied to the terminal VDD1 of CPU (LSI1), GATE ARRAY (LSI2) and RAM (LSI4). When IC2 receives the voltage, it provides 4V to the GND lines from the terminal OUT (Pin No.1).
2)
Main switch
The CPU (LSI1) detects the informations of the Main switch by the terminal SW (Pin No.36) from the SWO signal of the GATE ARRAY (LSI2).
3)
How to turn the display ON.
When pressing "ON" key under the ON side of the Main switch , the CPU (LSI1) generates the signal to turn the display ON on the terminal V2ON (Pin No.45). This signal goes to the terminal VIN (Pin No.24) of the GATE ARRAY (LSI2), then the GATE ARRAY (LSI2) generates "L" level on the terminal VOB (Pin No.28). When the transistor 2SA1179 (Q2) receives "L" level, the transistor 2SC2812 (Q1) will be also turned ON. Then LCD drive voltage V1~V4 will be applied.
4)
How to detect the voltage for the main batteries.
When the voltage of the VDD lines becomes +6.6V±0.18V, the terminal OUT (Pin No.1) of the detector RH5V60BA (IC4) becomes "L" level, then this signal goes to the terminal INTO (Pin No.70) of the CPU (LSI1) and the terminal PDN (Pin No.35) of the GATE ARRAY (LSI2). The CPU detects the low battery condition, then the display turns OFF.
� 10 �
|
|
|
> |
|
