MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
Filter Block Since the sound signal from the CPU is a stepped waveform, the filter block is added to smooth the waveform.
AVDD
T1 2SC1740SQ R6 R5 C5 R11 C9 C10 C11 R7 R8
From CPU
To Amplifier
AG
AG
AG
Amplifier/Voltage Regulator (IC1: AN8053N) Consisting of an amplifier and a voltage regulator, AN8053N amplifies the sound signal from the CPU and also provides the CPU +5V source. The following figure shows the internal block of IC1.
5V VREG 13
VCC 16
NC 15
CONT 14
NC 12
NC 11
NC PRE GND 10 9
5V REG POWER
SP AMP + 1 SPO 2 NC 3 4 5 PC-2 6 SPI 7
VREF
8 VREF
SP GND PC-1
SPM
