Settings (Speaker Setup 2)
The Distance, Test Start and Test Tone settings will be required when the P-01 is updated to allow playback of the DVD Audio format in the future. These settings have no effect on CD and SACD playback and are not necessary unless your P-01 is updated.
Start the Test Tone (Test Start)
Test tone function is useful for setting the relative levels of the speakers. 1. Select �Test Start� and press the ENTER button. The unit outputs test tone from each channel in turn at the specified level for each channel. < Adjust the master volume of your amplifier to the normal
Speaker distance
Ideally, the speakers should be placed so that they are all the same distance from the listening position. If this is not possible, you should use the method described here to adjust them individually. It is also possible to adjust all distances together. The point of these settings is to provide the best synchronization between sound and image by delaying the sound by an amount proportional to the distance of each speaker. The subwoofer is not included in this setting (the placement of the subwoofer is less critical than that of other speakers). The L/R setting changes the distance of all speakers together. Pressing the up button adds 0.1m to each value, and pressing the down button subtracts 0.1m from each value. Distances are measured in meters (1 meter = just over 3 feet, and 0.1 meter = about 4 inches). The default setting is 3m or about 10 feet.
listening level. 2. Select a speaker using the up or down cursor buttons. 3. Press the right cursor button. 4. Adjust the levels using the up or down cursor buttons. 5. When the setting has been finished, press the SETUP button to exit the setup menu.
Test tone length (Test tone)
Select the Test Tone menu item, and choose between 2, 5* or 10 seconds. This represents the length of time that the test tone is output from each speaker when Test Start is selected.
Carry out this operation first before setting the other speaker distances. After setting the L/R, C and SR/SL speaker distances together, you can now set the center and surround pair distances. The minimum distance for these is 0m and the maximum is 9m, with the additional restrictions described here. < The distance that you set for the center speaker cannot be greater than the distance set for the L/R pair and must be within 1.7m of that L/R distance. So for example, if the distance to the L/R pair is set to 5.0m, the center distance must be between 3.3m (5 � 1.7) and 5m. < The distance that you set for the SR/SL surround pair cannot be greater than the distance set for the L/R pair (and must be within 9m of that distance). So with the L/R pair set at 5m, the SR/SL pair distance can be set from 0m to 5m.
29
|
|
|
> |
|
