Important First, Fix one end of the earthing wire to the AC inlet metal of the power board(circuit). See the location indicated on the diagram (a1). Then, fix the other end of the earthing wire in the location indicated on diagram (a2). Important Fix one end of the other earthing wire to the AC inlet metal with a screw. Pass the wire through the slots in the ballast bracket as indicated in the diagram.
Affix the power board(circuit), and secure a washer and screw in the location indicated on the diagram.
First, attach the power board(ballast) to the ballast bracket. Place the ballast blacket onto the power board(circuit), and secure it in the location indicated on the diagram using two screws.
PJ-LC9(C12H)
30
Use M4 screws with crow washers Attach the fan, and secure two screws in the locations indicated on the diagram. After hooking the wire of the thermal switch(TSW) on the ballast bracket as shown in the diagram, Fasten the wire in the location indicated on the diagram, and secure it with two screws. Attach a magnet. fasten it in the location indicated in the diagram. Secure it in place using one screw. Attach the black insulation sheet to the location indicated in the diagram. hooks
Wiring diagram 2
|
|
|
> |
|
