Text excerpt from page 10 (click to view)
Mechanical Disassemblies
v Speaker, AV and DVI Board removal
1 Pull the speaker �SP901� upward off from the speaker groove. 2 Remove each screw A (M4x6) to release grounding wires. 3 Pull the Rear Panel ass�y upward off. 4 Remove 4 screws B (T3x6) and remove the AV Board and remove 3
screws C (T3x6) and remove the DVI Board. B A A Speaker C C B DVI board AV board
Fig.4
b Optical Unit removal
1 Remove 6 screws A (T3x8) and disconnect terminal �K6A� on the lamp ballast board. 2 Pull the Optical Unit upward off from the cabinet bottom. A A A A
