Text excerpt from page 76 (click to view)
CHAPTER 3. REPAIR INSTRUCTION
4
1. Place the camera so that the lens is set against the center part of the Color Viewer. 2. Click the �ADJUST� button.
Color Viewer
W-10 Filter CAMERA BODY Power Source Stand
Personal Computer
5
When the message on the right appears go to 6.
6
1. Attach the two W-10 Filters between the Lens and the Color Viewer. 2. Place the camera so that the lens is set against the center part of the Color Viewer. 3. Click the �ADJUST� button.
Color Viewer
CAMERA BODY
Power Source
Stand Personal Computer 7 When the message on the right appears, click the �FINISH� button. (This ends the �WB Calibration�.)
