Text excerpt from page 136 (click to view)
1
2
3
4
X DRIVE Assy
A
Diagnosis of the Video Card (PDA-5002)
1 2
Remove the Rear Case (50M). (Screws � 20) Remove the X DRIVE Assy. (Connector, Screws � 8)
1 2 3
Remove the Rear Case (50M). (Screws � 20) Remove the Video Card. (Screws � 2) Remove the SLOT CONNECTOR Assy from the RGB Assy and reconnect it with the Jig Cable (GGD1035).
Jig Cable (GGD1035)
SLOT CONNECTOR Assy RGB Assy
B
3 2 2
�2
3
�2
2
C
�2
2
�2
2 2
Video Card
2
X DRIVE Assy
4
Reconnect the Video Card. (Do not insert it into the slot.) Video Card
