Text excerpt from page 10 (click to view)
Playing with Different Tones
Other Effect Settings
You can select from among four reverb effects and four chorus effects by pressing the keyboard keys shown below.
1 Reverb Effect Keys 1: Room 2 3: Hall 2
Layering Two Tones
Use the following procedure to layer to two tones, so they sound at the same time.
PREPARATION
� If you plan to use a variation tone, perform the procedure on page E-6 to select the variation tone for the applicable TONE button(s) before starting this procedure.
0: Room 1
2: Hall 1
1
L C1 L C2 L C3 L C4 L C5 L C6 L C7 L C8 2 Chorus Effect Keys 1: Chorus 2 3: Chorus 4
While holding down the TONE button of one of the tones you want to use (the base tone), press the TONE button of the other tone (the layered tone).
Example: Press GRAND PIANO 2 button and STRINGS button at the same time.
0: Chorus 1
2: Chorus 3
1
While holding down the CONTROL button, press one of the keyboard keys shown above.
� This causes the indicator lamp of the base tone to light, and the layered tone to flash. � If the base tone (the one you pressed first) is a variation tone, the indicator lamp above the VARIATION button will light.
GRAND PIANO 2 STRINGS
� The tones are now layered.
2
After you are finished using the layered tones, press one of the TONE buttons again to unlayer them.
NOTE
� Note that you cannot layer the main tone and variation tone assigned to the same TONE button.
