8-5. HOW TO REMOVE HANDS
Please remove the hands according to the following procedure. 1) Prepare the following tool, Hand removing spacer.
Code No. 1901 9721
Parts name Hand removing spacer
Specification WAT-JIG510
FOB Japan N.R. Yen Unit price
2) Fix Hour, Minute and Second hands to the same direction. 3) Place Hand removing spacer on the EL dial. Be sure the two hands are in the hole of the hand removing spacer. 4) Remove the hands with the hand remover. Place the hand remover on the hand removing spacer as shown below. 5) How to fix the hands are the same way as the other watches.
Hand remover
Hand removing spacer
Movement holder
� 11 �
|
|
|
> |
|
