RCD-W500C
4-5. CD-RW Recording Adjustment and Self Record/Playback Check 1) Select the menu as follows. Control � Macro, and select 05cdrw_S.ttl. Press �Open�. Place the test CD disc PATD-012 on the Deck A. Place the recording CD-RW disc (see Note: 4-5-1) on the tray (Deck B) as prompted by the display and press �OK�. (Fig. 4-43) (The tray closes.) Note : 4-5-1 The disc to be used in this step. * * Use the CD-RW disc CWM74 for audio, that is manufactured by Sony. The disc that is used by this step cannot be used for the general purposes and for the purpose of operation check of the RCD series equipment as it is. The disc that is used for the general purposes or for the purpose of operation check of the RCD series equipment, cannot be used in this step. When you want to use the CD-RW disc for other applications, erase the CD-RW disc. If the recording is interrupted by any reasons during the recording operation (i.e., the WRITE POWER ON LED of the jig is lighting), the disc cannot be used any more in the subsequent step. In such a case, erase the CD-RW disc and repeat this step from the very beginning again. When the disc that is used in step 2) is the disc that has been used in the electrical adjustment in the past. ....... Press �Yes�. When the disc that is used in step 2) is a completely blank disc. ......... Press �No�. (Fig. 4-44) Note: The recording CD-RW disc can be used only for the electrical adjustment. The recording CD-RW disc must be controlled so that it must not be used for any other applications. 4) Press the H button of Deck A. After playback starts, press �OK�. (Fig. 4-45)
4 Fig. 4-43
2)
*
3)
4 Fig. 4-44
4 Fig. 4-45
5)
When the message as shown in Fig. 4-46 appears some seconds later, stop playback (1X) and select 4x of the test mode (refer to page 21, Play Speed Selection Mode (Deck A)) Playback Speed. Then press the H button of Deck A. After playback starts, press �OK�.
4 Fig. 4-46
47
|
|
|
> |
|
