Manual is in German but complete. I needed this one to fix a long lasting problem with the internal PSU of the camera. Most of the capacitors begin to leak after a few years wich results in the inability to power on the camera. When you try to turn it on the power led flickers and the unit directly turns off. Thanks to this manual I was able to locate all bad cap's and to dis- and reassemble the camera without any problems.
We received the manual in a timely manner and it was exactly what we were expecting.
Text excerpt from page 2 (click to view)
RDC-7UPG2 EXPLODED VIEW
Indicated only the parts which are an addition and change from RDC-7 with the model change to RDC-7UPG2. Please refer to RDC-7 service manual (No.3653 printed matter only) about the other parts. 1 DOOR and LABEL
The position to stick
UPGRADED
Center of DOOR
AV Controller RDC-7
2 1
2 Label on the Top cover
3
PARTS LIST
REF NO. 1 2 3 NAME DOOR LABEL LABEL DESCRIPTION --UPGS --PARTS NO. 28148512 29363154 29363164 QT'Y 1 1 1
