Text excerpt from page 9 (click to view)
PRACTICAL SERVICE FIGURE
< TUNER SECTION >
< FM SECTION >
Quieting sensitivity: (THD 3%) Less than 20dB (at 88.0MHz) Less than 19dB (at 98.0/108.0MHz) Less than 2% (Input 60dB) (at 98.0MHz) 10.7MHz
< DECK SECTION >
Tape speed: Distortion: Wow & Flutter: Test tape: 3000Hz+90Hz/-60Hz Less than 3% (PB) Less than 7% (REC) Less than 0.45% TTA-100
Distortion: Intermediate frequency:
< AM (MW) SECTION >
Sensitivity: (S/N 10dB) Less than 51dB (at 600kHz) Less than 49dB (at 1000/1400kHz) More than 30dB (Input 74dB) (at 1000kHz) Less than 3% (1000dB, 60% Mod) (at 1000kHz) 455kHz
