3. TAKING THE DISC OUT OF EMERGENCY
1. 2. 3. 4. Remove 8 screws on the top cover and remove the top cover. Remove 6 screws on the side panel and remove the side panel. Remove Power SW. Link. Remove 4 screws pointed with the arrows.
5. Disconnect all the wires at the right. 6. Remove the Mecha. component. 7. Turn the gear to the direction shown with your �nger and disc tray will opened.
