Setup 4: Bundle the cords and cables
1 2 3 Remove the arm cover. Bundle the cords and cables inside of the stand. Replace the arm cover and back cover.
arm cover
Setup 5: Turn on the monitor and computer
1 Press the MAIN POWER switch on the right side of the monitor in the direction of the [. The 1 (power) indicator lights up in red.
MAIN POWER
lights in red
1
2
back cover
3
2
Press the 1 (power) switch on the front right of the monitor. The 1 (power) indicator lights up in green.
lights in green
GB
Note If you cannot bundle all of the cords and cables inside the stand, leave them hanging down outside the stand.
3 4
Turn on the computer. Press the INPUT button to select the desired input signal. The selected input signal indicator lights up and the picture appears on the screen. For more information, see �Selecting the input signal (INPUT button)� on page 11.
The installation of your monitor is complete. If necessary, use the monitor�s controls to adjust the picture (page 12).
9
|
