EXPLODED VIEW AND PARTS LIST
NOTE:
� Items marked �*� are not stocked since they are seldom required for routine service. Some delay shoud be anticipated when ordering these items.
* : SP902 The model name is printed on the rear side of the speaker.
not supplied
SP901
5 2 6 1
* SP902
3
S
4
Ref. No. 1 1 2 3 4
Part No. X-4953-051-1 X-4953-262-1 4-874-614-11 4-932-425-01 4-229-774-01
Description
Remarks
Ref. No. 5 6 SP901 SP902 SP902
Part No. X-4953-050-1 1-757-017-11 1-529-801-11 1-529-802-11 1-529-900-11
Description PANEL ASSY, FRONT CORD, CONNECTION SPEAKER (TWEETER)(5cm) SPEAKER (WOOFER)(10cm)(CRB5) SPEAKER (WOOFER)(10cm)(CVB5)
Remarks
FRAME ASSY, GRILLE (CRB5) (LIGHT GRAY) FRAME ASSY, GRILLE (CVB5) (DARK GRAY) SCREW (4) (3.5X14), TAPPING SCREW (3.5X20) SCREW, ORNAMENTAL
9-929-527-11
Sony Corporation
Audio Entertainment Group
2
2000I1672-1 Printed in Japan ©2000.9 Published by General Engineering Dept.
|
|
|
> |
|
