Text excerpt from page 30 (click to view)
Customizing sound fields (continued)
Adjusting the bass and treble
The BASS +/� and TREBLE +/� button lets you adjust the tone (bass or treble) of the front speakers for optimum sound. You can adjust the tone for each separate sound field.
1 Start playing a program source
encoded with multi channel surround sound.
2 Press BASS +/� or TREBLE +/� to
adjust the tone.
The setting is stored automatically.
Initial settings
Parameter Initial setting
BASS TREB.
0 dB 0 dB
Bass (BASS)
Lets you adjust the bass tone.
Treble (TREB.)
Lets you adjust the treble tone.
Note
When you use the Micro Satellite Speakers or other small speakers, adjust LEVEL on the subwoofer (page 20) to reinforce the bass.
Resetting customized sound fields to the factory settings
1 If the power is on, press ?/1 to turn off
the power.
2 Hold down MODE and press ?/1.
�SF. CLR.� appears in the display and all sound fields are reset at once.
