Text excerpt from page 10 (click to view)
SCHEMATIC DIAGRAM
1 2
T-H300DAB
3 4 5 6 7 8
A
B
C
D
NOTES:
£Parts marked with this sign are safety critical components. They must always be replaced with identical components-refer to the appropriate parts list and ensure exact replacement.
INSTRUCTIONS FOR SERVICE PERSONNEL BEFORE RETURNING APPLIANCE TO THE CUSTOMER, MAKE LEAKAGECURRENT OR RESISTANCE MEASUREMENTS TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT.
E
T-H300DAB
DAB/AM/FM Stereo Tuner
1 st Issue; September 2003
