Hookups
Step 3: Connecting the Video Cords
Connect this player to your TV monitor, projector, or AV amplifier (receiver) using a video cord. Select one of the patterns A through D, according to the input jack on your TV monitor, projector, or AV amplifier (receiver).
S VIDEO Component video cord (not (green) (green) (blue) (blue) TV, projector, or AV amplifier (receiver) supplied) cord (not supplied)
Hooking Up the Player
Follow Steps 1 to 6 to hook up and adjust the settings of the player.
Notes
� Plug cords securely to prevent unwanted noise. � Refer to the instructions supplied with the components to be connected. � You cannot connect this player to a TV that does not have a SCART (EURO AV) or video input jack. � Be sure to disconnect the mains lead of each component before connecting.
Step 1: Unpacking
Check that you have the following items: � Audio/video cord (pinplug 3 y pinplug 3) (1) � Remote commander (remote) (1) � R6 (size AA) batteries (2) � Stand (1) � Screw (1) � A EURO AV adapter is included with European models.
(red) TV, projector, or AV amplifier (receiver)
(red)
(green) to COMPONENT VIDEO OUT
(blue)
(red)
to S VIDEO OUT CD/DVD player
DIGITAL OUT
PCM/DTS/MPEG/ DOLBY DIGITAL
COMPONENT VIDEO OUT
Y CB CR
Step 2: Inserting Batteries into the Remote
You can control the player using the supplied remote. Insert two R6 (size AA) batteries by matching the 3 and # ends on the batteries to the markings inside the compartment. When using the remote, point it at the remote sensor on the player.
(yellow) (yellow)
OPTICAL
S VIDEO OUT LINE OUT
R AUDIO L VIDEO
(yellow)
to LINE OUT (VIDEO) (yellow)
TV, projector, or AV amplifier (receiver)
Audio/video cord (supplied)
(yellow)
Notes
� Do not leave the remote in an extremely hot or humid place. � Do not drop any foreign object into the remote casing, particularly when replacing the batteries. � Do not expose the remote sensor to direct light from the sun or a lighting apparatus. Doing so may cause a malfunction. � If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage from battery leakage and corrosion. TV EURO AV adapter (supplied with European models) Audio/video cord (supplied)
l : Signal flow
16
,continued
17
A If you are connecting to a video input jack
Connect the yellow plug of the audio/video cord (supplied) to the yellow (video) jacks. You will enjoy standard quality images.
Yellow (Video) White (L) Red (R) Yellow (Video) White (L) Red (R)
First turn off the player by pressing @/1, and then press @/1 again while holding down x on the player. The player turns back on, and the name of the colour system scrolls across the front panel display.
Note
Do not connect the player to a VCR. If you pass the player signals via the VCR, you may not receive a clear image on the TV screen. If your TV only has one audio/video input jack, connect the player to this jack.
Hookups
VCR
Use the red and white plugs to connect to the audio input jacks (page 21). (Do this if you are connecting to a TV only.)
CD/DVD player TV Connect directly
B If you are connecting to an S VIDEO input jack
Connect an S VIDEO cord (not supplied). You will enjoy high quality images.
C If you are connecting to a SCART (EURO AV) input jack (European models only)
Connect the EURO AV adapter (supplied with European models) to the SCART (EURO AV) input jack of the TV, and connect the player and the EURO AV adapter using the audio/video cord (supplied). Connect the yellow plug of the audio/video cord to the yellow (video) jack. Use the red and white plugs to connect the audio input jacks (page 21).
Yellow (Video) Yellow (Video) TV White (L) EURO AV adapter Red (R) White (L) Red (R)
For European models: When you play a disc recorded in the NTSC colour system, the player outputs the video signal or the Setup Display etc. in the NTSC colour system and the picture may not appear on the PAL colour system televisions. In this case, open the tray and remove the disc.
D If you are connecting to a monitor, projector, or AV amplifier (receiver) having component video input jacks (Y, CB, CR)
Connect the component via the COMPONENT VIDEO OUT jacks using a component video cord (not supplied) or three video cords (not supplied) of the same kind and length. You will enjoy accurate color reproduction and high quality images.
Green Blue Red Green Blue Red
When connecting to a standard 4:3 screen TV
Depending on the disc, the image may not fit your TV screen. If you want to change the aspect ratio, please refer to page 57.
To change the colour system (Asian/Oceanian models only)
If the on-screen menu of the player does not appear on the connected TV, switch the player�s colour system to match the colour system of the TV (NTSC or PAL).
18
19
1-4
|
|
|
> |
|
