XR-CA600X/CA620X
3-5.
GUIDE (C)
2 guide (C)
1 three claws
3-6.
MOUNTING POSITION OF CAPSTAN/REEL MOTOR (M901)
two precision screws (P2 � 2)
capstan/reel motor (M901)
Note: Mount the motor so that the angle between of the motor and the hole for the screw becomes 30° as shown in this figure.
30�
